|Daily output in summer in Germany (Wh/d)||220|
|Rated output (Pmpp) Wp||55|
|Short-circuit current (Isc) A||2,54|
|Open-circuit voltage (Uoc) V||27,13|
|Current (Impp) A||2,40|
Appearance and design.
- Stability and maximum heat dissipation due to aluminum-sandwich-plate.
- Thanks to innovative cell-chaining technique semi-flexible (up 3%) mountable.
- Extremely resistant protective Nowoflon film on front and back.
- Particularly flat and glued screwed cable outlet with strain relief.
- Well known since 20 years.
- Already prepared cable gland in the carrier plate.
- 5 kg.
Long lifetime even under extreme conditions.
- Extremely high yields through the use of crystalline high performance cells.
- Maximum daily yield by additional single cells.
- Powerful low-light performance – High yields even under cloudy and partially shaded conditions.
- External cell protector with bypass diodes offers protection against cell overheating (Hot-Spots) is included.
