| General |
|
| Input voltage |
100 - 240 VAC |
| Input frequency |
50/60 Hz |
| Input current |
1.5 A |
| Input connector |
EU (Type C) |
| Output voltage |
48 VDC |
| Output current |
1.3 A |
| Output connector |
2-PIN, with cord end terminals |
| Weight |
305 g |
Additional
|
|
| Input voltage absolute maximum |
90 - 264 VAC |
| Input frequency absolute maximum |
47 - 63 Hz |
| Maximum input inrush current |
50 A |
| Output voltage absolute maximum |
45.6 - 50.4 VDC |
| Short circuit protection |
✓ |
| HIPOT (dielectric withstand test) |
Primary to Secondary: 4000 VDC |
| MTBF |
50000 h |
| Certification |
Safety: EN 61558-1:2005/A1:2009, EN 61558-2-16:2009/A1:2013 (CB Scheme)
EMC: EN 55032:2012+AC:2013, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015 |
