| General |
|
| Input voltage |
100 - 240 VAC |
| Input frequency |
50/60 Hz |
| Input current |
3.9 A |
| Input connector |
EU (Type F) |
| Output voltage |
54 V |
| Output current |
4.62 A |
| Output connector |
2-PIN, with cord end terminals |
| Weight |
1080 g |
Additional |
|
| Input voltage absolute maximum rating |
90 - 262 VAC |
| Input frequency absolute maximum rating |
47 - 63 Hz |
| Maximum input inrush current |
60 A |
| Output voltage absolute maximum rating |
51.3 - 56.7 VDC |
| Short circuit protection |
✓ |
| HIPOT (dielectric withstand test) |
Primary to Secondary: 1500 VAC |
| Certification |
Safety: IEC62368-1 (CB Scheme)
EMC: EN 55032:2015, EN IEC 61000-3-2:2019,
EN 61000-3-3:2013, EN 61000-4-2:2009,
EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-4:2012,
EN 61000-4-5:2014, EN 61000-4-6:2014, EN 61000-4-8:2010,
EN 61000-4-11:2004 |
