| Input voltage absolute maximum |
90 - 264 VAC |
| Input frequency absolute maximum |
47 - 63 Hz |
| Maximum input inrush current |
50 A |
| Output voltage absolute maximum |
47.5 - 52.5 VDC |
| Short circuit protection |
✓ |
| HIPOT (dielectric withstand test) |
Primary to Secondary - 4242 VDC |
| MTBF |
50000 h |
| PSU efficiency standard |
DoE Level VI |
| Certification |
Safety: EN 60335-1:2012+A11:2014+A13:2017, EN
60335-2-29:2004+A2:2010+A11:2018, EN 62233:2008
EMC: EN 55014-1:2017, EN 61000-3-2:2014, EN
61000-3-3:2013, EN 55014-2:2015 (IEC 61000-4-2:2008, IEC
61000-4-4:2012, IEC 61000-4-5:2014, IEC 61000-4-6:2013, IEC
61000-4-11:2004+A1:2017) |
